The SVAC2 Vacuum Oven from SHEL LAB is a high-performance laboratory vacuum oven designed for fast, gentle drying of heat-sensitive materials. Its innovative design enables drying at lower temperatures than conventional convection ovens, preventing residue buildup and protecting delicate samples from thermal damage.

Constructed with a seamless stainless steel chamber and a double plenum design, the SVAC2 meets UL, CSA, and EU safety standards while maintaining a cool outer surface. Users can select a 3/8-inch orifice or a KF25 fitting to achieve precise vacuum levels quickly, with a maximum permitted end vacuum of 10 mTorr and a leak rate of 10 mTorr per hour.

The vacuum oven features spring-loaded tempered glass doors with positive latch handles, providing a secure vacuum seal without hinge stress, extending gasket life. The viewing window allows continuous monitoring of samples. Silicone gaskets resist a wide range of temperatures and pressures, with optional Buna, Fluorosilicone, or Viton® gaskets recommended for solvent or acidic applications.

Note: The SVAC2 does not include a vacuum pump or accessories. Contact your SHEL LAB distributor to select compatible pumps and accessories for your application.

Key Features:

• Watlow controller capable of 40-step ramp and soak profiles or four files with 10 steps per file

• High-performance vacuum levels for efficient drying

• Sizes range from 0.6 to 9 cu.ft to accommodate various workloads

• Built-in over-temperature protection for safe operation

• Seamless stainless steel chamber for durability and easy cleaning

• Spring-loaded tempered glass doors with secure vacuum seal

• 24-month limited warranty

Applications:

Ideal for drying heat-sensitive materials, pharmaceutical and chemical research, biological sample preparation, polymer and electronics testing, and low-temperature vacuum drying in laboratories and industrial environments.
